PEEK-FC series modified by PTFE, graphite and carbon fiber have lower friction coefficient, wear resistance and self-lubrication than pure resin G.
Carbon Fiber Reinforced PEEK (CA Grades)
These grades are reinforced with carbon fibers, which significantly enhance the material's wear resistance, making them ideal for high-performance applications where low friction and long-lasting durability are crucial. Our 330CA, 550CA, and 770CA both have great wear resistance.
Friction & Wear Resistant PEEK (FC Grades)
This series is specifically formulated for applications that demand excellent wear resistance. These grades are engineered to withstand harsh operating conditions, providing superior performance in sliding and rotating components.
PEEK (polyetheretherketone) materials are used at extremely high temperatures (approx. 260 degrees), have extremely high stiffness and hardness, and have a unique high tensile and fatigue strength.
In addition, its heat resistance and chemical stability are excellent. The material has excellent dielectric properties until temperatures reach 260 degrees and is resistant to energy rays. PEEK has excellent comprehensive properties, good mechanical properties, high temperature resistance, and excellent chemical resistance, making it the most versatile high-grade plastic.
Features: The maximum allowable working temperature in the air is very high (can work continuously at 260 degrees, up to 310 degrees in a short time), mechanical strength, high rigidity and hardness, high temperature resistance, excellent chemical resistance, and hydrolysis resistance, excellent wear resistance and friction resistance, extremely high creep strength, excellent dimensional stability, excellent ultraviolet resistance, excellent high-energy radiation resistance, inherently low flammability, and less smoke when burning.
